Free Installation Busbar Punching and Shearing machine

$10000 - 50000 /Set/Sets

Payment Type:

L/C,T/T

Incoterm:

FOB,CFR,CIF,EXW

Min. Order:

1 Set/Sets

Transportation:

Ocean

Contact Now

 Chat Now

Product Description

Product Attributes
Supply Ability & Additional Information
Packaging & Delivery

< >

Overview

Product Attributes

Model No.: EMAC-BP-40/60

Brand: Euro-Asia/Gaoji

Whether CNC machine tool: Cnc

status: New

Machine type: Hydraulic Press

Nominal force (kN): 1600

power: Hydraulic

place of origin: China

Core selling point: Automatic

warranty period: 1 Year

Applicable industry: Manufacturing Plant, Machinery Repair Shops, Energy & Mining, Construction Works, Advertising Company, Other

Out-of-warranty service: Video Technical Support, Online Support, Field Maintenance And Repair Service

Where to provide local services (in which countries are there overseas service outlets): India

Showroom location (in which countries are there sample rooms overseas): None

Marketing type: Hot Product 2019

Mechanical test report: Provided

Video factory inspection: Provided

Core component warranty period: 1 Year

Core components: Bearing, Pump, Motor, Plc, Pressure Vessel, Other, Engine

Supply Ability & Additional Information

Packaging: Seaworthy packing

Productivity: 20Sets/Month

Transportation: Ocean

Place of Origin: Shandong, China

Supply Ability: 200Sets/Year

Certificate: ISO

Payment Type: L/C,T/T

Incoterm: FOB,CFR,CIF,EXW

Packaging & Delivery

Selling Units:: Set/Sets

Package Type:: Seaworthy packing

Advantages:
1. Busbar Machine With Punching And Shearing machine software--This is our independent patent in busbar processing, which can realize 3D automatic programming and dynamic simulation.
2. Double clamps--Comparing other single clamp, double clamps can make processing more accurate and stable.
3. Hydraulic system-- Piston pump (rather than gear pump) has large drive power and realize high efficiency.

4. Main components--Imported, so the quality and service life can be guaranteed.

Main techincal parameters

Technical parameter
Description		Unit	Parameter
Press Force	Punching Unit	kN	500
	Shearing Unit	kN	500
	Embossing Unit	kN	500
X Max Speed		m/min	60
X Max Stroke		mm	2000
Y Max Stroke		mm	530
Z Max Stroke		mm	350
Stroke of Hit Cylinder		mm	45
Max hit speed		HPM	□120 □150
Tool	Punching Mould	set	□6 □8
	Shearing Mould	set	□1 □2
	Embossing Mould	set	□1
Control Axis			□3 □5
Hole Pitch Accuracy		mm/m	±0.20
Max hole punch size		mm	Φ32( Thickness of Copper bar <12mm)
Max embossing area		mm²	160×60
Max Allowable sheet dimension(LWH)		mm	6000×200×15
Total power		kw	14
main machine dimension:L*W		mm	7500X2980
Total weight		kg	7600

Packing details:

Exhibition show

Looking for ideal Free Installation Machine Manufacturer & supplier ? We have a wide selection at good prices to help you get creative. All the Installation Free Machine are quality guaranteed. We are China Origin Factory of Installation Free Busbar Machine. If you have any question, please feel free to contact us.
